| Size | Ply Rating | Tread Depth(mm) | Standard Rim | Overall Dimension(mm) | Max Load(kg) | Relevant Pressure(kpa) | |
| Section Width | Overall Dia | ||||||
| 9.00-16 | 14★★ | 16 | 6.50H | 255 | 890 | 1720 | 630 |
| 8.25-26 | 14★★ | 14 | 6.50H | 235 | 855 | 1705 | 730 |
| 7.50-16 | 12★★★★ | 12.5 | 6.00G | 215 | 805 | 1320 | 770 |
| 7.00-16 | 12★★★★ | 12.5 | 5.50F | 200 | 775 | 965 | 630 |
| 6.50-16 | 10★★ | 11 | 5.50F | 185 | 750 | 860 | 530 |
| 6.00-16 | 10 | 11 | 4.50E | 170 | 730 | 755 | 530 |
| 6.50-15 | 10 | 11.5 | 4.50E | 180 | 730 | 825 | 420 |
| 6.00-15 | 10 | 10.7 | 4.50E | 180 | 705 | 630 | 420 |
| 6.50-14 | 10 | 11.5 | 4½J | 530 | 690 | 690 | 530 |
| 6.00-14 | 10 | 10.5 | 4½J | 170 | 680 | 600 | 420 |
| 6.00-13 | 10 | 10 | 4.00E | 170 | 655 | 580 | 420 |
| 5.50-13 | 8 | 10 | 4.00B | 160 | 620 | 500 | 420 |
| 6.00-12 | 6★★ | 16 | 4.50E | 145 | 650 | 405 | 250 |
| 5.50-16 | 10 | 9 | 4.00E | 110 | 670 | 1350 | 530 |
| 5.00-16 | 10 | 9 | 3.00D | 95 | 645 | 1200 | 600 |
| 4.00-12 | 6 | 8 | 3.00D | 70 | 510 | 240 | 360 |
